带座轴承代号

外形尺寸 (mm)

带座轴承重量 (kg)

配用轴承代号

配用轴承座代号

D

B

S

L

J

A

A1

A2

N

ds

UCF201

47

31.0

12.7

86

64

25.5

11

15

12

M10

0.7

UC201

F204

UCF202

47

31.0

12.7

86

64

25.5

11

15

12

M10

0.7

UC202

F204

UCF203

47

31.0

12.7

86

64

25.5

11

15

12

M10

0.6

UC203

F204

UCF204

47

31.0

12.7

86

64

25.5

11

15

12

M10

0.6

UC204

F204

UCF205

52

34.1

14.3

95

70

27

13

16

12

M10

0.8

UC205

F205

UCF206

62

38.1

15.9

108

83

31

13

18

12

M10

1.0

UC206

F206

UCF207

72

42.9

17.5

117

92

34

15

19

14

M12

1.4

UC207

F207

UCF208

80

49.2

19.0

130

102

36

15

21

16

M14

1.8

UC208

F208

UCF209

85

49.2

19.0

137

105

38

16

22

16

M14

2.2

UC209

F209

UCF210

90

51.6

19.0

143

111

40

16

22

16

M14

2.4

UC210

F210

UCF211

100

55.6

22.2

162

130

43

18

25

19

M16

3.6

UC211

F211

UCF212

110

65.1

25.4

175

143

48

18

29

19

M16

4.4

UC212

F212

UCF213

120

65.1

25.4

187

149

50

22

30

19

M16

5.5

UC213

F213

UCF214

125

74.6

30.2

193

152

54

22

31

19

M16

6.1

UC214

F214

UCF215

130

77.8

33.3

200

159

56

22

34

19

M16

6.9

UC215

F215

UCF216

140

82.6

33.3

208

165

58

22

34

23

M20

8.1

UC216

F216

UCF217

150

85.7

34.1

220

175

63

24

36

23

M20

8.3

UC217

F217

UCF218

160

96.0

39.7

235

185

68

24

40

23

M20

21.0

UC218

F218
