Home > Products > deep groove ball bearing > > deep groove ball bearing 16000 Series
Product name : deep groove ball bearing 16000 Series
自定义参数 :
自定义参数 :
 Enlarge Image                   Back
←[Previous Product]              [Next Product]→


Details:


16000 Series


Prodcut Name:16000 Series

Product Description



Bearing Bore O.D. Width Chamfer Load Rating Ball Complement Maxrunout speed Weight
No . d D B r/min
  mm mm mm mm Dynamic Static No. Size Grease Oil KG
          Cr Co mm r/min r/min
16001 12 28 7 0.3 5.1 2.4 8 4.763 20000 26000 0.019
16002 15 32 8 0.3 5.6 2.8 9 4.763 19000 24000 0.0252
16003 17 35 8 0.3 6 3.3 10 4.763 18000 22000 0.03
16004 20 42 8 0.3 7.9 4.5 10 5.556 16000 19000 0.048
16005 25 47 8 0.3 8.8 5.6 12 5.556 13000 17000 0.059
16006 30 55 9 0.3 11.2 7.4 12 6.35 11000 14000 0.0.85
16007 35 62 9 0.3 12.2 8.8 14 6.35 95000 12000 0.107
16008 40 68 9 0.3 12.6 9.8 15 6.35 9000 11000 0.13
16009 45 75 10 0.3 15.6 12.2 15 7.144 8000 10000 0.167
16010 50 80 10 0.3 16.1 13.1 15 7.144 8000 95000 0.175
