Home > Products > deep groove ball bearing > > deep groove ball bearing 6800 Series
Product name : deep groove ball bearing 6800 Series
自定义参数 :
自定义参数 :
 Enlarge Image                   Back
←[Previous Product]              [Next Product]→


Details:


6800 Series


Prodcut Name:6800 Series

Product Description



Bearing main dimension(mm) basic load rating(kgf) rotational speed(rpm) Weight
No . Bore O.D. Width Chamfer Dynamic Static Greese Oil (KG)
  d D B r/min Ce Co Z.ZZ RS.2RS Z
              RU.2RU
6800 10 19 5 0.3 175 86 37000 - 43000 0.005
6801 12 21 5 0.3 195 105 33000 - 39000 0.006
6802 15 24 5 0.3 210 130 28000 - 33000 0.007
6803 17 26 5 0.3 265 160 26000 - 30000 0.008
6804 20 32 7 0.3 410 250 21000 - 25000 0.018
6805 25 37 7 0.3 440 300 18000 - 21000 0.022
6806 30 42 7 0.3 460 350 15000 - 18000 0.026
6807 35 47 7 0.3 485 390 13000 - 16000 0.03
6808 40 52 7 0.3 505 425 12000 - 14000 0.033
6809 45 58 7 0.3 630 550 11000 - 13000 0.04
6810 50 65 7 0.3 670 620 9600 - 11000 0.052
6811 55 72 9 0.3 895 825 8700 - 10000 0.083
6812 60 78 10 0.3 1170 1080 8000 - 9400 0.104
